300amp Restrained Plug - New Macey
Sealing compound
Stainless steel construction
Serviceable bolted body
Termination choices
300 Amp restrained plug for 660V / 1100V systems, with stainless steel 304 construction and a serviceable bolted body.
Quick Specifications
Rated Current: 300 Amp
Rated Voltage: 660V / 1100V
Material: Stainless steel 304
Weight Before Termination: 9.5 kg
300 Amp Restrained Plug
300 Amp restrained plug for 660V / 1100V systems, with stainless steel 304 construction and a serviceable bolted body.
300 Amp660V / 1100VStainless steel 3049.5 kg before termination
Overview
The New Macey 300 Amp Restrained Plug is designed for 660V / 1100V systems. Its stainless steel 304 construction and bolted body provide access to the cable termination for servicing.
The sealing compound helps protect the termination from water ingress. A three-way grommet clamp applies even torque, while the custom reusable grommet is designed for resistance to chemical corrosion.
Features & Benefits
- 1Sealing compound – Helps prevent water ingress into the cable termination.
- 2Stainless steel construction – Robust construction for heavy-duty use.
- 3Serviceable bolted body – Provides access to the termination with fewer parts.
- 4Termination choices – Contact our team to confirm grub screw, crimp or solder options.
- 5Three-way grommet clamp – Applies even torque around the grommet.
- 6Reusable custom grommet – Designed for reuse and resistance to chemical corrosion.
Technical Specifications
300 Amp
660V / 1100V
Stainless steel 304
9.5 kg
Australia
Confirm the right product for your application
Contact New Macey for product selection and technical assistance, or request a quote.
